Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Yep, that's an emergency. Good for that city crew which spotted it, but it also raises the question of why this got so bad before inspections identified the problem. Or don't they do inspections in Chicago?

I know this bridge has been there for a long time, but it vividly demonstrates why halving joints should be avoided, IMHO.

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

June 2018 FWIW:

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Looks like it was already failing in 2018.
Note the difference in the two bottom flanges relative vertical positions...
and the dark "slot"? just off the end of the angle.

Check out Eng-Tips Forum's Policies here:
FAQ731-376: Eng-Tips.com Forum Policies

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Steel is a wonderful material, but it is not indestructible.

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

My wife is always making fun of me whenever we walk through or under some structure and my eyes are scanning the framing for "issues".
I've never found one significant but this Chicago failure is just what I'm looking for smile

Check out Eng-Tips Forum's Policies here:
FAQ731-376: Eng-Tips.com Forum Policies

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

I'm going to show your post to my wife, JAE. Just so she knows that I am not the only one. I have found and acted on some issues over the years, maybe not as important as that one.

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

My wife thinks i am the only one that does that sort of thing.(As in the looking for failures etc)


Regards
Ashtree
"Any water can be made potable if you filter it through enough money"

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Along with me, wife has started looking for suspect area. She finds some, too.

www.SlideRuleEra.net idea

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

I'm struggling to understand why the joint was put in there in the first place, with a pier just a few feet away. Why not just use a double bearing pier?

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

My observation and question as well HotRod10! I guess if design looked bad when built, then it was just a matter of time to prove it was bad design!

Walt

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Second photo shows joint was shimmed to get roadway elevation uniform. Combine impact force/vibrations from roadway elevation difference and gap along with corrosion source and poor upkeep, no wonder the poor design finally "almost" failed.

Walt

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

We still have a few pin and hanger connections around, but I've never seen one like that.

It might have been ok if they had maintained it and not let the top flange connection and web rust away...

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

HotRod - Riveted construction... that bridge screams late 1920's-1930's Great Depression time frame. Top priority... avoid material expense, concrete in this case. Why make an entire pier twice as thick when the spans can be supported as shown on a "thin" pier?

www.SlideRuleEra.net idea

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

You're probably right, SRE. Had they maintained a seal on the joint above and kept paint on it, it would likely have been fine.

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

(OP)
Expected to be closed until at least tonight while they erect temporary shoring towers to stabilize the girders. Permanent repairs would then follow.

https://www.chicagotribune.com/news/local/breaking/ct-met-lake-shore-drive-river-bridge-closure-20190211-story.html

Quote:


Scheinfeld said the cracks were first noticed by a crew making traffic signal repairs around 10 a.m. Monday. An engineering crew came to the scene and decided to shut down the roadway.

Seven steel girders run north and south along the roadway at that point underneath the viaduct structure near expansion joints, Scheinfeld said. Two of the seven girders have cracks. She said the city plans to install steel plates underneath the roadway as a permanent repair.

Scheinfeld said the bridge is inspected every two years and was due to be inspected again in June. It was deemed in fair condition when last inspected in June 2017, she said.

Section damaged was built in 1986. Kind of confusing, but believe the 'structurally deficient' comment is about the nearby bridge rather than the currently failed section:

Quote:

The damaged section, built in 1986, is just south of the steel bascule double-decker bridge over the Chicago River, which was built in 1937. It is one of the most heavily traveled structurally deficient bridges in the state, according to the American Road & Transportation Builders Association, a Washington-based trade group that uses Federal Highway Administration figures. The association said that the bridge is “functionally obsolete.”

The term “structurally deficient’’ means that a bridge is in need of repair or rebuilding, according to the association. The Chicago Department of Transportation is planning repairs to this bridge together with the Navy Pier Flyover bike path construction project this year.

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Built in 1986! I missed the age by 50 years, or so. Bridge has had a hard life.

www.SlideRuleEra.net idea

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

They built this when they fixed the infamous S curve. That curve was a traffic engineering disaster. Two sharp curves in an area that would ice up with the lake water spray.
In looking at Google-Maps, they have the same connection on the Southbound side too (a little further south than this one).

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

to all the other engineers who have wives that mock you with things like "ooooooh steeeeeel" and "look at that concrete over there...ahhhhhh"

my people!

RC


RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Built in '86 or 'modified in '86'?
I wonder when it was shimmed, that should have been a red flag right there.

= = = = = = = = = = = = = = = = = = = =
P.E. Metallurgy, Plymouth Tube

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Yes, when there's rust on the edge of the fracture - not a good look for the bridge inspectors.

Check out Eng-Tips Forum's Policies here:
FAQ731-376: Eng-Tips.com Forum Policies

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

I kept wondering where the other cracked beams were; it turns out one of them was hiding behind the one in most pictures:

TTFN (ta ta for now)
I can do absolutely anything. I'm an expert! https://www.youtube.com/watch?v=BKorP55Aqvg
FAQ731-376: Eng-Tips.com Forum Policies forum1529: Translation Assistance for Engineers Entire Forum list http://www.eng-tips.com/forumlist.cfm

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

For that connection to even work on paper it seems like there should be horizontal flanges/stiffeners at the seat, going at least the depth of the seat back into both beams.

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Hows that work with the current cycling temp extremes?
Wish the pic showed the problem area.

Keith Cress
kcress - http://www.flaminsystems.com

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

Why do those shoring towers look like they're riveted together?

Brad Waybright

It's all okay as long as it's okay.

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

I thought that too Brad. The speed they appeared makes it likely they already existed just for that job. Did they have to fix this bridge before?

RE: Northbound Lake Shore Drive Bridge (in Chicago) Closed For ‘Structural Emergency’

No way guys... those are pre-fabricated, modular, bolted shoring towers. You'd have to call around for towers able to carry these kinds of loads, but in a town like Chicago, they're sitting in some contractor's yard somewhere.

As far as temperature effects... most towers are flexible enough to not offer a lot of restraint/stability in the longitudinal direction. They're only there for vertical support. Presumably, the longitudinal load path wasn't affected by this failure.

----
The name is a long story -- just call me Lo.
