I have just started to use the Catia V5 R21. I have an assembly consising of „two parts” (drum.png). I would like to make a draft from this assembly. I would like to set default colors for each parts in drafting (capture.png)
[URL=http://kepkezelo.com/]
[/URL]
[URL=http://kepkezelo.com/]
[/URL]
[URL=http://kepkezelo.com/]
[/URL][URL=http://kepkezelo.com/]
[/URL]




RE: Catia V5 drafting
RE: Catia V5 drafting
If you want to color only boundaries you can use for example Inherit 3D Color setting, if wish to have something like an area fill use raster view.
Regards
Fernando
