How can I get the charcoal sketch effect with SW or NX?

How can I get the charcoal sketch effect with SW or NX?

(OP)
Hello


After creating a model..
How can I get a pencil effect similar to these ones with NX or SW?
I don't know if I can achieve it with their default renderers or if I need some special render, such as Keyshot.
I don't know if I can get it while viewing the model in 3D or if it's just for 2D drawings or even if I need to postprocess the image with photoshop.

regards



RE: How can I get the charcoal sketch effect with SW or NX?

2
While I can't speak for Solid Edge, with NX, go to...

View -> Visualization -> Artistic Image...

...where you will find eight different 'rendering' engines which can be used to produce various types and styles of 'Artistic' Images. Below is an example showing first the normal shaded image of a model, then an image using the 'Hand Drawn' rendering engine set to produce as smooth and as accurate an image as possible and the lastly, using the same 'Hand Drawn' rendering engine, only this time with settings which produced an image with a much more of a 'hand drawn' appearance:







Below are three additional example using first the 'Cartoon' Rendering engine, followed by a 'Stipple' and 'Pencil Shading' examples:







Anyway, I hope this is that sort of thing that you were looking for.

John R. Baker, P.E.
Product 'Evangelist'
Product Engineering Software
Siemens PLM Software Inc.
Industry Sector
Cypress, CA
Siemens PLM:
UG/NX Museum:

To an Engineer, the glass is twice as big as it needs to be.

RE: How can I get the charcoal sketch effect with SW or NX?

Seems a bit ironic to have spent all the money and development to produce these highly accurate and precise design tools to get rid of vellum drawings, yet there are these tools to make the drawings look like vellum drawings.

TTFN
FAQ731-376: Eng-Tips.com Forum Policies

RE: How can I get the charcoal sketch effect with SW or NX?

(OP)
Nice

RE: How can I get the charcoal sketch effect with SW or NX?

IRstuff, it's all about keeping marketing/management happy.

Just be careful, if Sales/Marketing/Management see a an image that looks vaguely like the real thing they'll assume all the engineering is done and they're ready to release.

Posting guidelines FAQ731-376: Eng-Tips.com Forum Policies http://eng-tips.com/market.cfm? (probably not aimed specifically at you)
What is Engineering anyway: FAQ1088-1484: In layman terms, what is "engineering"?

RE: How can I get the charcoal sketch effect with SW or NX?

Another issue, which is often even more critical, is when you've been asked to submit a proposal to a customer, showing him what appears to be a finished design will often give them the impression that they are no longer in a position to make suggestions for improvements and they may even feel that they've lost control of the project. Showing them something that still looks like the project is in the 'concept' phase may result in a more satisfied customer when the final designs are approved since they will have more confidence that their feedback and ideas were actually taken into consideration.

John R. Baker, P.E.
Product 'Evangelist'
Product Engineering Software
Siemens PLM Software Inc.
Industry Sector
Cypress, CA
Siemens PLM:
UG/NX Museum:

To an Engineer, the glass is twice as big as it needs to be.

RE: How can I get the charcoal sketch effect with SW or NX?

In my experience, the customer is inclined to make suggestions/changed right AFTER they still were in that position and when the design was already approved.
But maybe that's just me..

NX 7.5.5.4 with Teamcenter 8 on win7 64
Intel Xeon @3.2GHz
8GB RAM
Nvidia Quadro 2000

RE: How can I get the charcoal sketch effect with SW or NX?

Hm I just tried this and nothing happens when I click 'OK'. What am I missing, do I need some special license for this?

NX 7.5.5.4 with Teamcenter 8 on win7 64
Intel Xeon @3.2GHz
8GB RAM
Nvidia Quadro 2000

RE: How can I get the charcoal sketch effect with SW or NX?

In this particular case, clicking 'OK' simply saves the settings and closes the dailog. The issue is that this particular dialog has not had it's 'UI refresh' yet so it still uses and older scheme where you initiate the function from WITHIN the dialog itself. In other words, the overall dialog is just a 'task environment' from in which you select your method, set your options and launch a render operation. So what you need to do is select the 'Start Shade' button as shown below:



BTW, the icon next to it erases the image.

Once the image has been created, you can use either the...

File -> Export -> PNG... (or whatever image format you wish; JPEG, GIF, TIFF or BMP)

...to capture the image on your screen.

John R. Baker, P.E.
Product 'Evangelist'
Product Engineering Software
Siemens PLM Software Inc.
Industry Sector
Cypress, CA
Siemens PLM:
UG/NX Museum:

To an Engineer, the glass is twice as big as it needs to be.

RE: How can I get the charcoal sketch effect with SW or NX?

Still nothing :(

I can see it say 'processing geometry' but nothing happens after that.

NX 7.5.5.4 with Teamcenter 8 on win7 64
Intel Xeon @3.2GHz
8GB RAM
Nvidia Quadro 2000

RE: How can I get the charcoal sketch effect with SW or NX?

I don't know, it's always worked for me.

John R. Baker, P.E.
Product 'Evangelist'
Product Engineering Software
Siemens PLM Software Inc.
Industry Sector
Cypress, CA
Siemens PLM:
UG/NX Museum:

To an Engineer, the glass is twice as big as it needs to be.

RE: How can I get the charcoal sketch effect with SW or NX?

Do you have a studio visualize license?
I do not and the artistic image looks like it is going to work but produces nothing. I tried creating a high quality image but was limited to gouraud shading. At least the high quality image command was nice enough to tell me why it wasn't working.

www.nxjournaling.com

RE: How can I get the charcoal sketch effect with SW or NX?

Since the license sheet on my system covers ALL of our products (you wouldn't expect anything else now would you ;-) it's not that easy to 'test' what happens if and when a license is NOT present. Granted, I can verify whether a license was needed to make it run (and it is, being checked-out when you hit the 'Start Shade' icon and being checked back in as soon as the rendering is finished), but as for what happens if it's not there, well...

That being said, I'll take it up with the developer(s) and have them check the software.

John R. Baker, P.E.
Product 'Evangelist'
Product Engineering Software
Siemens PLM Software Inc.
Industry Sector
Cypress, CA
Siemens PLM:
UG/NX Museum:

To an Engineer, the glass is twice as big as it needs to be.

RE: How can I get the charcoal sketch effect with SW or NX?

Walterke,
Perhaps you need to evangelise more. wink

RE: How can I get the charcoal sketch effect with SW or NX?

(OP)
The only drawback with this method is that it can only create still images and not a continuous rendering.

If somebody is interested I've found that this drawing are also called xylograph, stipple, engraving, guilloche, hedcut or pencil shading. Just google it and you could find alternative ways to get it with other programas as well.

regards

RE: How can I get the charcoal sketch effect with SW or NX?

I already assumed that I would need an extra license for this and was actually surprised when the menu opened. Guess I cheered a bit too early.

I'll try that evangelising. Maybe I need bigger glasses as well.

NX 7.5.5.4 with Teamcenter 8 on win7 64
Intel Xeon @3.2GHz
8GB RAM
Nvidia Quadro 2000
